CCMT120408MPLCP25T (CCMT 120408-MP LCP25T) BOEHLERIT

Product data
chip breaker MP
grade LCP25T
delivery quantiy min 10
name of tool system drehen-ISO
P1 main 120 - 250
P2 main 100 - 220
corner angles [EPSR] 80
clearance angle main cutting edge [AN] 7
length of cutting edge [L] 12.9
inner circle [IC] 12,7
cutting edge height [S] 4.76
corner radius [RE] 0.8
insert execution r/n/l [IH] N
insert height [S1] 4.76
cutting material [GRADE] LCP25T
coating [COATN] CVD
insert size CCMT 1204
edges/ insert 2
coating K-alpha
insert shape CCMT
Norm [NSM] DIN-4000-76
M1 secondary 90 - 130
P3 main 80 - 200
P4 main 70 - 170
P5 main 80 - 190

Internal Reference: 5055848
Marca:: BOEHLERIT
