P06.ST25.020.12 Y X800) simmill PX Milling Insert, Dovetail milling 45°, tmax=2,5 mm, Dmin=12 mm, R=0,2 mm, SIMTEK

Description Value
J20 Technical product number P06ST2502012YX800
J21 Identifying order number P06.ST25.020.12 Y X800
J3 Company code SIM - Simtek
NSM Standard number of properties layout DIN4000-82
BLD Tool style code 4
A1 Cutting diameter 0.460630 in
A2 Cutting diameter maximum 0.263780 in
B2 Depth of cut maximum 0.098425 in
B3 Protruding length 0.137795 in
B5 Overall length 0.161417 in
B71 Functional length 0.133858 in
D6 Rotational speed maximum 13000 1/min
D7 Weight of item 0.001 kg
E1 Tool cutting edge angle 135 Degree
F1 Cutting direction R - Right
F21 Peripheral effective cutting edge count 6
F22 Face effective cutting edge count 6
F27 Cutting edge centre count 0
F3 Flute helix hand N - Hand of helix neutral
F4 Flute helix angle 0 Degree
F71 Number of corner designs 1
F72 Corner design 1 - radius
G1 Corner radius 0.007874 in
H11 Standard designation of the grade, main application HC
H21 Coolant entry style code 0 - Without coolant entry
H22 Coolant exit style code 0 - Without coolant exit
H3 Grade manufacturer's designation X800
H4 Body material code H - Solid carbide
H5 Coating TiAlN
J7 Data chip provision 0 - Without data chip

Internal Reference: A03H-X800
