MÁQUINA SIERRA CINTA HORIZONTAL TIPO TIJERA SEMI-AUTOMATICA, CONO CORTE ANGULAR COSEN (copia)

SH-500M
Semi-Automatic Horizontal Scissor Style, Mitering Band Saw
Swivel saw head allows miter cutting from 0 degrees to 60 degrees
Hydraulic cylinder plus precision ground hinge support
Hardened worm gear for durability
Hard-stops at , 45, and 60 degrees for quick angle set up
Blade drive equipped with variable pulley system
Adjustable flood coolant system
Motor driven, synchronized wire blade brush
Carbide blade guides and bearing provides additional blade support
Rigid cast-iron guide arms
Cast-iron hydraulic vise
Adjustable down feed control
Adjustable material stop



Saw head automatically raises after each cut
Capacity Angle 0 +45 +60
Round Capacity 13" 11.8" 8.6"
Rectangular Capacity 11" x 19.7" 11" x 9.4" 11" x 8.6"
Blade Speed 60Hz: 75, 114, 164, 246 FPM
Blade Size (LxWxT) 13' 7" x 1" x .035"
Blade Motor 3 HP
Coolant Motor 1/8 HP
Coolant Tank Capacity 7.9 gal
Hydraulic Tank Capacity 2.08 gal
Workbed Height 32.6"
Weight 1,980 lbs
Floorspace (LxWxH) 80.5" x 41.6" x 57.8"

Internal Reference: SH-4030
Marca:: COSEN
